House Electric Wire

PRODUCT CODE

1、Series code
B：fixed wiring R：Connecting flexible wires
2、Insulation material code
V：PVC insulation YJ：Crosslinked polyolefin insulation
3、Combustion performance code
N: Fire resistance W: halogen-free D: low smoke Z: flame retardant

USAGE
This series of products is suitable for fixed connections of power, lighting, electrical equipment, instruments and telecommunications equipment with rated AC voltage of 450/750V and below.

Usage characteristics
1) The rated power frequency voltage U0/U is 450/750V;
2) When used in DC systems, the nominal voltage of the system should not exceed 1.5 times the rated voltage of the cable;
3) The cable laying temperature shall not be lower than 0 ℃;
4) The maximum allowable long-term working temperature for cable conductors is BV type, which does not exceed 70 ℃, while others do not exceed 90 ℃.
5) Bending radius: not less than 6 times the outer diameter.
